Pressure Integrity & Site Safety Calculators

From the design office to the field. Screen vessel thickness and MAWP, confirm capacity and calibration, size overpressure relief to API practice, then carry that integrity mindset onto site with construction-safety utilities for EPC and refinery work.

ASME VIII API 520 / 521 Volume / Calibration Field Safety

Vessel & Relief Schematic

// Category 03 – Pressure equipment & relief

Vessels, volume & overpressure

The static-equipment package: wall thickness and MAWP screening, capacity and calibration, and relief sizing for credible overpressure scenarios.

[ 03.1 ]

ASME VIII Pressure Vessel Calculator

Screen shell and head thickness, MAWP and basic vessel geometry against ASME VIII Division 1 rules as a rule-based integrity check.

ASME VIII Div.1MAWPThickness

Open calculator

[ 03.2 ]

Vessel Volume & Calibration Calculator

Total and partial volumes for common head types, plus calibration and strapping output for level-to-volume conversion.

Partial VolumeHeadsStrapping

Open calculator

[ 03.3 ]

Tube Rupture Relief Valve Suite

Estimate relief loads and PSV sizing for tube-rupture and other overpressure cases following API 520 and 521 practice.

API 520API 521PSV Sizing

Open suite

// Category 04 – Field safety & construction

From design to site

Carry integrity thinking into execution with field-safety and construction utilities aimed at oil and gas, EPC and refinery environments.

[ 04.1 ]

Field Safety & Construction Utility Suite

A field-oriented toolkit for construction and safety engineering tasks across oil and gas, EPC and refinery projects, built for offline site use.

ConstructionField SafetyEPC / Refinery

Open suite

[ 04.2 ]

Why pair safety with integrity?

Pressure integrity and site safety are two sides of asset protection. Grouping them keeps the people who size relief systems and the people who execute the work inside one trusted toolkit.

Asset protectionOne workflow

// Engineering basis

Built for defensible screening

Code-awareASME VIII Division 1 and API 520 / 521 methods for screening checks.

No copied tablesRule-based integrity logic, with no reproduction of copyrighted code tables.

Field-readyOffline tools that run on site with no install or connection.

AuditableTransparent inputs and outputs suited to review and sign-off.

// Common questions

Integrity & safety FAQ

Do these tools replace ASME or API code calculations?

No. They are rule-based integrity and relief screening tools that apply the public methods from ASME VIII Division 1 and API 520 and 521. They support early checks and reviews but do not reproduce copyrighted code tables and are not a substitute for a stamped code calculation by a qualified engineer.

What overpressure scenarios does the relief suite cover?

The suite focuses on relief-load estimation and PSV sizing for cases such as tube rupture and other common overpressure scenarios, following the sizing approach set out in API 520 and the scenario guidance in API 521.

How accurate is the vessel volume and calibration tool?

It computes total and partial volumes for standard head geometries and produces strapping or calibration output for level-to-volume conversion. Accuracy depends on the dimensional data you enter, so confirm against the certified vessel drawing for custody or inventory use.

Can the field-safety suite be used on site without internet?

Yes. Like every AIEnginear tool it is fully self-contained, so once the page has loaded it runs offline in the browser – useful for refinery, EPC and construction environments with limited connectivity.

// Explore the toolkit

Other brand hubs

FlowStack – Process & Hydraulics 01 IntegriShield – Integrity & Safety 02 MechCore – Mechanical & Energy 03

Screening and educational use. IntegriShield tools apply public code methods to support engineering judgement and review. They do not reproduce copyrighted code tables and must be verified against the governing code edition, project basis and a qualified engineer before procurement, construction or operation.
